3.3MWh High-Performance Lithium Battery Storage System with 40 kW Aux.Power Consumption

Name: 33MWh HighPerformance Lithium Battery Storage System with 40 kW AuxPower Consumption
Brand: SHPN
Price: 1 USD

Brand Name : SHPN

Model Number : L3300-BAT

Certification : IEC62477-1 / IEC62040-1 / IEC62619 / IEC63056 / UKCA / CE LVD / CE EMC / UN38.3 / VDE-AR-E 2510-50

Place of Origin : China

MOQ : 1 units

Price : consult prices online

Payment Terms : T/T

Supply Ability : consult online

Packaging Details : consult online

System Capacity (kWh) : 3317

DC Voltage range (Vdc) : 1036.8~1382.4

Life Cycle : >8500

Depth of Discharge : 98% (single string)

Dimension (W*D*H mm) : 6058*2438*2896

Contact Now

3.3MWh High-Performance Lithium Battery Storage System with 40 kW Aux.Power Consumption

Product Description:

3.3MWh High-Performance Lithium Battery Storage System with 40 kW Aux.Power Consumption

The M8-20ft-3.3MWh energy storage system is a high-capacity, cutting-edge solution designed for large-scale energy storage applications. With an impressive 3317 kWh capacity and a wide DC voltage range of 1036.8 to 1382.4 V, it provides exceptional performance for grid-level operations and critical backup systems. Equipped with advanced liquid cooling technology and a robust design, it operates reliably in temperatures ranging from -20℃ to 50℃, ensuring consistent efficiency and safety. The system is certified under global standards such as IEC62477 and UL9540A, making it a dependable choice for demanding environments. With aerosol fire suppression and optional C3H/C5 anti-corrosion features, the M8 system offers unparalleled safety and durability.

Battery System	M8-20ft-3.3MWh
System Capacity(kWh) 3317
DC Voltage range (Vdc)	1036.8~1382.4
Life Cycle	>8500
Depth of Discharge	98%(single string)
Dimension(WDH mm)	605824382896
Weight (tons)	30
Protection Class	IP55
Altitude (m)	≤3000
Humidity(RH)	95%
Cooling System	Liquid Cooling
Cooling System Consumption(kW) 120
Aux.Power Consumption(continuous/peak,incl.HVAC)(kW)	40
Working Temperature Range(℃)	-20~50*
Fire Extinguishing	Aerosol
Communication Type	RS485/CAN/Ethernet
Operation Logic	Ancillary Service/Electricity Arbitrage/Demand Response/Backup
Certification*	IEC62477-1/IEC62040-1/IEC62619/IEC63056/UK CA/CE LVD/CE EMC/UN38.3/VDE-AR-E 2510-50
Anti-Corrosion	C3H(C5 Optional)

Application Scenarios

3.3MWh High-Performance Lithium Battery Storage System with 40 kW Aux.Power Consumption

Grid-Scale Energy Balancing:
- The M8-20ft-3.3MWh system is tailored for utility-scale energy balancing, seamlessly integrating into the grid to manage energy peaks and valleys. Its high capacity and efficiency enable operators to stabilize the grid, reduce outages, and optimize energy distribution.
Critical Infrastructure Backup:
- Designed for hospitals, data centers, and other essential facilities, this system ensures uninterrupted power supply during emergencies. Its robust design, including IP55 protection and advanced liquid cooling, provides reliable performance under the most challenging conditions.
Renewable Energy Storage:
- The system excels in renewable energy applications by storing surplus energy from wind and solar farms. Its high cycle life (>8500) and deep discharge capability (98%) ensure maximum energy utilization, supporting sustainable energy transitions.
Industrial Energy Independence:
- For industries with high energy demands, the M8 system offers a reliable solution for peak shaving and energy cost reduction. Its modular design and advanced communication protocols (RS485, CAN, Ethernet) ensure easy integration into existing industrial systems.

The M8-20ft-3.3MWh energy storage system represents the pinnacle of modern energy storage solutions, delivering unmatched performance, reliability, and adaptability to meet the evolving demands of global energy management.

Shipping Methods

Supports global air and sea shipping

If you require more detailed product information or have customized requests, please contact us. Providing efficient service that satisfies our customers is our responsibility.
